High Frequency TNC female Connector flange Chassis mount waterproof solder for cable

  • tnc KYD Connector

Part NO.: YRL-624-009
Tags: RF Coaxial Connector,TNC flange connector,solder connector,Female tnc connector
Material: POM/Brass/Nickel plated
Features:

  • 12 Months Quality Insurance
  • Free sample available for quality test
  • Compact Design for less installation space required
  • Easy quick connect and disconnect coupling
  • High cost-effective with good quality
  • High cost-effective with good quality
  • Can be Customized for unique material or performance requirement
Get Free Samples and Price Quotes

High Frequency TNC female Connector flange Chassis mount waterproof solder for cable

Housing Material Gold/Nickle plated TNC connector
Connection Type Cable mount, Impedance 50 Ohm / 75 Ohm available
Frequency Range 0-4 GHz
V.S.W.R Straight type ≤ 1.22/3GHz, R/A type ≤ 1.30/3GHz
Working Temp Teflon -55℃~+155℃ / POM -40℃~+60℃
Packing Carton box or OEM package available.
Shipping Most of orders are shipped with FedEx/DHL/UPS/TNT/SF, for bulk qty order we also can arrange for air shipping,sea shipping as well.
Lead Time around 3~7 days for samples, 7~12days for bulk order.
Payment We accept bank transfer in T/T, Paypal & Western Union, or other payment methods.
